“ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER TECHNOLOGIES (AMMLIT)”
“Intrusion & Objects Shapes Technologies & Methods””Gas affected by Magnetics”
Easy to understand description: Introduction
The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is basically a Material Objects Finder Separator Devices, so the reader can understand, and only as a remote example, it is in the vein of a Standard Metal Detector, but does not use any it’s technologies or methods; The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is far advanced and has Superior & Enhanced New Technologies that uses very different and important methods of manufacturing and assembles, only possible with new and advanced materials, integrated circuit, 3-D Printing, and glues. The Intrusion Technologies & Methods mentioned above are applied in some of the devices (apparatus) and are utilizing part of the Earth Motion Movement Magnetic Fields Energies; this is described later in this USPTO application. I do cite other prior art, but also I have extra non-related patent info that may help the reader understand the concepts of Intrusion Technologies & Methods.
General Description, needs and justification
With all the bombing and explosions in our society a device that finds these awful destructive devices are needed, along with a device that can find artifacts and hidden treasures and precious materials in the earth and in space, to help all mankind, this describes such a device/apparatus, the
“Advanced Materials Magnetic Locator Identifier (AMMLI)”
The “Advanced Materials Magnetic Locator Identifier (AMMLI)” Finds almost all the known natural and manmade elements (materials) and other combination of different elements/materials together (different materials/Elements in one object) in and above the Earth (planets and also in the cosmos) at long-range, distant. The Advanced Materials Magnetic Locator Identifier uses the new Intrusion Technologies & Methods that can be manufactured in many different physical forms and configurations.
Listed below: Items listed can be an Active (Xmit), or a Passive (Receive) mode of operation, or both. Any of the apparatus/devices can work in almost all environments, and operated un-detected. They can also work with small Cell phones, tablets, and micro-computer like a TI Bagel Black Bone, Arduino.
1.) It can be a Flat Plate Finder Apparatus (FPFA) like a Wall-Plate on the side of a flat surface of a Building (see Fig 1.), Vehicle, Drone, Space-Ship, Rectangular Box; just about any object can house the Flat Plate Finder Apparatus. The Flat Plate Finder Apparatus (Wall-Plate) plate has sensors and electronics embedded in it; it senses different things like hidden objects, people, elements, at a long-range, up to several miles. It has a reporting system and sends information back to the internet via Wi-Fi, or other methods. It can also be manufactured in Nano Size or larger. It has three sub-parts, the flat plate, and central general computer, mechanical hardware to remotely lock doors or other mechanical devices.
2.) Or a Hand-Held Handheld Disruptor Unit (HHDU) a type of device like a Radar gun that the police use, but this unit is a small Hand-Held device that can be mounted in just about any object, it is similar in shape to the Radar gun, but is a lot different in relation to the new technology mentioned in this application. It is called the Handheld Disruptor Unit (HHDU). It too can be mounted on a drone or other type of vehicle.
3.) Or a Reactive Rotating Barrel Unit (RRBU)that finds and detects objects in the Earth Fields or Space. The RRBU barrel can be manufactured in Nano form or as big as a skyscraper building, depending on its application. This device can either gather (collect)or disrupt the Earth magnetic fields depending on how it is applied. This is spinning cone barrels to attract the Earth Fields
4.) Or an Elements Discriminator Apparatus Locator (EDAL) device that uses a camera and a pulsed wave transmitter to find and detect hidden objects for a range of two miles or more. The EDAL pulsed waves are pointed at a target and the frequencies penetrate the front of to back of the target and the frequencies actually reflect back to the camera pointed in parallel with the pulsed wave device. The software then converts the images and sees what is hidden. This device uses a somewhat similar technology.
All of these apparatus/devices use some forms of Intrusion Technologies to find hidden objects, and also it can be used as a measurement tool in extreme high temperatures for capturing data in most environmental conditions and finds deep hidden objects inherent in the Earth and Space, it is good to finding artifacts for archeologist. William G. Birchard is the inventor of the Materials Objects Finder Separator Devices apparatus, and methods that are sued in the commonly known Advanced Materials Magnetic Locator Identifier. This technology and equipment uses the Intrusion Methods and hardware and software to accomplish this amazing real world finder and identifier/locater. These are the original inventions, devices, ideas and theories of William G. Birchard. These inventions are built on His Technologies, Theories, Methods, Hardware/Software, and was created by William G. Birchard; technologies listed in this Patent.
US Patent Application #:
Abstract: Background of invention:
1. Field of the invention: The present invention relates to a Earth Motion Magnetic Fields Technologies, Motion Movement Low Energy Magnetic Finder Technology used in the “A Finder Intrusion & Disruption Technologies / Methods”, all in the Super Blue Domain Polyshift Technology V family, The Advanced Materials Magnetic Locator Identifier is like a ground plate or side wall flat plate placed in different positions for finding and detecting many different materials, compounds, liquids, gases, drugs, guns, knives, and explosives (Fig 2). The Advanced Materials Magnetic Locator Identifier can also detect Precious Materials and a variety of other devices. The Advanced Materials Magnetic Locator Identifier has the capabilities (software algorithm) of testing for different combinations of materials /compounds to determine if the mixtures are volatile or not. In additional to detecting explosive and other explosive devices the Advanced Materials Magnetic Locator Identifier can also detect all types of movements of most any masses detecting individual elements, including humans and animals, living and non-living things. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER has a very big advantage over other detectors in that it is a very long-range detector reaching up to 1000 feet (or more) above and below the Earth, or in Water and is very accuracy. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER can detect very small quantities, less than500 grams (in most cases), in and above the earth and in some cases 6-10 Meters deep or more. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER can penetrate through walls (most materials), cars, trucks, and many other obstacles while moving in a high speed vehicle. The present invention is found very useful in Law enforcement, customs, military, Airports, and in all security environments. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is unique because it can be used under water for deep sea exploration, and can be operated remotely; this also has great applications for biochemical / hazardous lab conditions. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is completely autonomously and reports all if its information wirelessly back to a security link over the internet or using secured communications. The technology has passed all tests with 100 % accuracy, and No failures. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is a non-destructive detection/locator device allowing it to verify whether there are any guns, weapons (Metal or Non-Metal Shapes), knife or explosive materials, bombs, or any biochemical threats at a given location, or remote locations. Guns and Explosive detection is commonly used at airports, ports, border, buildings, military / field location and national defense , (it Finds most all of the Elements). One of the many uses of the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is to detect Guns, knives, Explosives, or other incendiary devices and Stop terrorist from detonating them, or anyone killing and destroying life or property. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER also has the ability to locate landmines. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is the a basic plate (a board with sensors like coils embedded within) and works within Two (2) Wall Plate sensors, software, a control box, associated hardware as needed, and this total unit is also a wireless system Fig 1. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER saves lives and prevents loss of property.
2. Description of related Art: The major problem associated with current material and explosive detectors is that they have a very short range, large, not reliable, and cost a lot of money. Many types of Guns, Explosives, bombs, and biochemical / hazardous materials (IED and other homemade devices) present a real world threat at airports, schools, government, and transportation operations. This presents a major loss of life, and masses damage to property. Some of the current state of the art detections things being used are Dogs, Mechanical scent detection, X-ray machines, and Neutron activation, Spectrometry, all of which have a very short operating range and are not very reliable for a given time. A Taggant can mean a radio frequency microchipused in automated identification and data capture like RFIDor a certain additive added into the explosives. In such cases, electronic devices use radio waves to track and identify items, such as pharmaceutical products, like explosives, not all countries adhere to this convention and many bombs are homemade and not traceable. Some of the devices listed previous are hazardous to humans and cost in the $1 Million USD range. Other like dogs can only operate for shorts periods of time. There are a number of bogus devices like the dowsingdevise. None of these attempts to create devices that can detect specific materials such as explosives (or any materials for that matter) have been proven successful in controlled double-blind scientific tests. In fact, all testing of these inventions has shown these devices to perform no better than random chance. A number of dowsing rod-style detection devices have been widely used in Iraqand Thailand, notably the ADE 651 and GT200, where they have been reported to have failed to detect bombs that have killed hundreds of people and injured thousands more. The US of America has put over 10 Billion dollars of research money to make an Explosive detector, detection devices and the best the US government has are canine dogs. The need for a reliable material / explosive detector (low cost) is badly needed to save lives.
Brief description of the drawing
A clearing understanding of the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER invention will be seen with reference to the following description and drawings.
Fig. 1is a ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER material explosive detection system. Fig. 1 illustrated a perspectives view of Material Detector locator device.
Fig 1 below
Description of the preferred Embodiment
Overview of the BMD device:
The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER plate systems are built on Motion Movement Low Energy Electromagnetic Principles, utilizing advances computer programming, unique mechanically designed coils, and low frequency pulsed wave transmitters. WGB has built and tested ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER. This was done with major defenses contractors in the USA. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is a Material detector locator system that has passed all tests with 100 % accuracy, and No failures. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER can detect most any type of explosives materials or different combinations of materials at a long range*(in the ground also). The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER works on receiving Electromagnetic energy from the existing Earth Electromagnetic fields, and manmade disturbance energy.
The “SUPER-DTUBEE” is a cylinder type unit made for deep exploration to locate hidden materials in sub-depths of the Earth it is frequently call the Advanced Materials Magnetic Locator Identifier (AMMLI).
The Passive Barrel Unit (PBU) and Small Materials Detector (SMD) were devices that use a somewhat similar technology as the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER; known as the PBU, SMD were custom field demonstration models in a different form. We illustrate them in a Pictorial representation because they are built similar to customer specifications. Most all of the units are built to the requirements of our customers, and keep extremely confidential. All detectors designs are customer proprietary information, and No detectors designs (hardware or software) are ever used as a sample or demonstration model. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER (Fig. 1) finders/detectors are used to tested special materials in laboratory and fields conditions. These can units passed with 100 % success, and No failures. The ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER is custom models built to a proprietary customer’s specification; the units in the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER document don’t necessary represent a true physical picture of the plate, the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER can be almost any configuration. The SMD Small Material Detector Locator (Hand Held Unit)) was designed for fast, and in close detection of the target (Hidden Materials). The Reactive Rotating Barrel Unit (RRBU) was designed for buildings and more of a stationary application, but can be used in vehicles.
Basic ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER demo units:
The basic ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER units can be manufactured in most any physical configuration; this type of configuration / design would be considered a stand-alone units. Stand-alone units only require power and only need to be mounted to most any solid surface.
General Theory of operation: Named the “ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER”
A very Complex High Field CloudEnergy Wave is transmitted from a directional Antenna / Plate. This is a continuous big burst of CloudEnergy (very directional) similar to a Wave of Magnetic Motion transmitted out to the target; (The Key is the Complex Field of Wave and rich in Harmonics Pulsation, we use and special software algorithms). We then have a receiving set of Motion Antennas that capture part of this wave of motion (Harmonics Pulsation). This is new coil technology design and theory, but very solid and well-grounded in Electromagnets. The coils are wound in a certain method so it distorts an oscillation field pattern that is feed into the coil. This distorts oscillation pattern from the coil is feed into the Antenna, where it is transmitted. The Antenna is of a certain design and has to be tuned physically to the oscillations field (earth field) patterns. In fact the whole system mechanically and electrically has to be in Harmonic Field Balance (regulate). On the receiving coil they capture the Distorts Oscillation Energy (DOEP) Patterns. The Distorts Oscillation Energy Patterns are converted to a Digital bit stream of twelve (12) packets. There are 12 packets that contain all the information form one (1) burst of field energy Transmitted. As the Received Distorts Oscillation Energy, Patterns are being captured in the center (in the heart of the receiving coils, special wound coils) of the receiving coil. The receiving coil has four (4) receptors (small probes that actually strip off the information from the center of the coil) this is where the Electromagnet to Digital conversion happens. These 2/4 (main) receptors are feed into a set of digital latches that capture the digital bit streams and stores them in real time. The sample time is bases on the number three, 3 times the digital bit streams (4) = 12 packets of information each XX mill second to another set of Bi-polar latches. XX is a classified number, so are the frequencies. At this point the 12 packets of information are ready for the PIX chip (microcontroller), computer CPU is ready to process the RAW packets of information from the coils. This is where the Digital Signal Processing (DSP) software (embedded algorithms) processes the data and starts to decipher the patterns. The DSP software is another Key to the operation of the device. To understand the general operation of the DSP algorithms you need to understand the how we use the Distorts Oscillation Energy Patterns. The DSP algorithms are built on the Rate of Change of the Distorts Oscillation Energy Patterns that they receive. The Dv/Dt FN (rate of change) Patterns are integrated over a period of time (integrated over a lower limit –upper limit. As each set of patters (12) are processed the first set of patterns are stored. Then the second sets of patterns are stored and so on until 12 sets are stored. There are two methods of DSP algorithms that can be used.
The first methods where we examine and interrogate the Distorts Oscillation Energy Earth Patterns as strictly an Energy Patterns that will all ways have an exact Field Signature Recognition Code (FSRC) for any type of Material. This means that all materials (of any weight, size, composition, shape or not ), has a certain unique Field Signature Recognition Code (FSRC) that describes it and identifies it as a unique pattern that the DSP software can store in a Database and attach a label to it so we ( uses) can recognize any type of material. So each FSRC is stored in a relational Database and compared to a known set of FSRCs. The FSRC are a pattern and are converted to a Digital Recognition Code (FSRC) that the computer can understand. The FSRC are then displayed on a LCD (OLED) and read by the operator. The FSRC can be read as a direct description (any language displayed), like C4 and the weight, size, composition, shape, speed, distant, amount, location can also be viewed. The software is very complex and it is too much for this paper to address, complex this topic. The software is very intensive effort and has many safe guards built in to it. The FSRC can also be up loaded to a Satellite connection or encrypted and sent over the internet. The Reactive mode can be utilized with very low power and has much Noninvasive application but can obtain the same results as a Dynamic mode. One of the advantages of the Reactive mode is it uses a One Shot Energy Patterns Transmitting to the Antenna and thereby reducing power requirements and emissions. In certain application this is very important. The Reactive mode can be used in Non-Pulse transmissions guns and Dynamic transmissions guns.
The second method where we examine and interrogate the Distorts Oscillation Energy Patterns as strictly a Energy Patterns that will all ways be changing and have a certain rate of change (Dv/Dt) (FN) but still produce an exact Signature Recognition Code (FSRC) for any type of Plateer / Material. This means that all plateer (of any weight, size, composition, shape or not ), has a certain unique Field Signature Code (FSRC) that describes it and identifies it as a unique pattern that the DSP software can store in a Database and attach a label to it so we ( uses) can recognize any type of material. So each FSRC is stored in a relational Database and compared to a known set of FSRCs. The FSRC codes area in this model are a set of changing patterns and are converted to a Field Digital Recognition Code (FSRC) that the computer can understand. The FSRC are then displayed on a LCD and read by the operator. The FSRC can be read as a direct description (any language displayed), like C4 and the weight, size, composition, shape, speed, distant, amount, location can also be viewed. Using the Dynamic Mode the FSRC is always in motion. What make this method very different is this technology gives a dynamic reading on the display, not a static reading. The software is still very complex and it is too much for this paper to address, complex this topic. The software is very intensive effort and has many safe guards built in to it and using the Dynamic mode requires more and much more complex software. The FSRC can also be up loaded to a Satellite connection or encrypted and sent over the internet. The Dynamic Mode can be utilized with low power, but in most cases will require High Power for the Pulsed Energy, and is very invasive. One of the applications is to transmit a High Energy Pulse. The application is C4 or any other type of material can be altered. One advantages of the Dynamic mode is to use a Multi Shot Energy Pulses Transmitted to the Antenna and there by sending out a Large Burst of power in a tunneled direction to certain target. In certain application this is very important, in the Dynamic Mode this method becomes an offensive device. The Dynamic mode can be used in Pulse transmissions guns and Dynamic transmissions guns. In the Dynamic mode this technology can be used to disable many different things.
How it works: Dynamic Mode, Transmitting a Pulse Pulsation Wave “ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER”
A simple Description:
Simply put, any material compound or plateer will affect a Pulsated Pulsed Wave by changing its complex harmonics molecular structure (Digital Code Pattern). A Pulsed Wave is comprised of a rich in harmonic frequency signal (A modulated carrier, of a High Frequency Pulse) that is emitted from a High Frequency Coil and is fed by a Push pull Oscillator that changes Phase, frequency and varies within the Natural Earth waves pattern, for a given geographic location. When this Pulsed Wave is emitted (Reactive or Non Reactive) its complex harmonics molecular structure is altered. The Analog/Binary Signature Recognition Code is changed and set to a different alignment kind of like changing the Magnetic pattern on a CD or Magnet tape. We capture this rate of change signal and integrate it into slices of time and store it in memory.
We extract this signal from a set of coils and transducers and stores integrated integrals and integrate the signal over a period of time and store these slices of Signatures Reconciliation Code to memory. We then in software build a recreated picture of the Analog/Binary code (input signal). After we recreate this 3 D picture and Patterns we send it to a PIX chip. The PIX chip performs Digital Signal Processing (DSP) algorithms that will pre-define a data base value and rename and the composition it is scanning.
This scanned picture is then changed to a well-defined digital look up code that is stored in Permanent memory (Hard drive). The Digital Patterned is then sent to an Application Program (AP) that will format it and convert to a digital display then sent to a LCD or LED read out. The operator can then read the results on LCD or LED screen.
Our detection devices can be designed as either Reactive or Dynamic, pertaining to the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER. The technology is a little different to the BMDL and the PBU devices. A Reactive device is a receiver, a non- intrusive device that Finds signatures from a generated disturbance field. This device would reactively survey a targeted area for traces of certain materials. The results of this Reactive data gathering would then be fed into a computer program. The computer would analyze the gathered data, compare it to known materials in its database and then deliver results to the display and activate preprogrammed alert systems.
Dynamic devices act similarly, however a Dynamic device would send out a signal and get a reflective signal back, like radar. The Dynamic device would be capable of identifying materials at a greater distance than the Reactive device. The results of this Dynamic data gathering are then fed into a computer chip and the results are then delivered to the display and viewed by the operator.
This is truly a remarkable device. This unit has many applications and cost is very low. It is also safe and easy to use. It is about the size of a radar gun and can be power by remote sources.
This technology is built on The New Poly Blue Domain theory V. This is not Super Blue Domain Poly-Shift IV
Nomenclature ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER AMMLI-AMMO12-14
Classification Material Finder Detection Locator System & Technology “identifier and finder”
Code name: Materials Objects Finder Separator Devices (MOFS) MOFS121219-227
Physical Sizes: Handheld Disruptor (HHD) (10”X12”X6”), Potable Reactive Rotating Barrel Unit (RRBU) (size depends on the application),
General Physical Size: inches, Combined ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER Plate Systems, the size may vary
Dynamic Unit Size: ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER Plate Classified *
ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER -Plate has the following properties: Dynamic and Reactive models
Ammunition, TNT, C-4, and Gun powder, Nitroglycerin, fertilizer, baking soda, ammonia, RDX/NITRATE, UREA NITRATE, TATP/HMTD, CHLORATE/BROMATE, NITROGLYCERIN, NARCOTICS. Most all types of liquids, solids, gases
Some Specifications are classified, but we provide some general figures so the customer has some general-purpose details about the products. Some customers may need these to get familiar with the ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER S specification. The actually sizes can be very small. .
Add-on and Options:
All ADVANCED MATERIALS MAGNETIC LOCATOR IDENTIFIER models can have the following options: Electronics Specifications
**Options call or email
